THE CM-MPS.41P IS A MULTIFUNCTIONAL RELAY FROM THE CM THREE-PHASE MONITORS RANGE. IT OPERATES WITH A RATED CONTROL SUPPLY VOLTAGE / THREE-PHASE MEASURING VOLTAGE OF 300-500 V AC 50/60 HZ AND HAS A 2 C/O (SPDT) OUTPUT WITH CONTACTS RATED AT 250 V / 4 A. THIS RELAY MONITORS ALL PHASE PARAMETERS SUCH AS OVER/UNDERVOLTAGE, PHASE UNBALANCE AND PHASE FAILURE. THE CORRESPONDING THRESHOLD VALUES ARE ADJUSTABLE. PHASE SEQUENCE MONITORING AS WELL AS AN ON OR OFF TRIPPING DELAY ARE SELECTABLE. THE TRIPPING DELAY IS ADJUSTABLE OVER A RANGE OF INSTANTANEOUS TO 30 S (0, 0.1-30 S). A SEALABLE TRANSPARENT COVER FOR PROTECTION AGAINST UNAUTHORIZED CHANGES IS AVAILABLE AS ACCESSORY. THE DEVICE OFFERS MAINTENANCE FREE EASY CONNECT TECHNOLOGY WITH PUSH-IN TERMINALS. PACKING UNIT: 1

SD203/63 SWITCH DISCONNECTOR 3P, 63A, PACKING UNIT: 1

OVR T2 1N 40-275 P TS QS SURGE PROTECTIVE DEVICE, PACKING UNIT: 1

OVR T2-T3 1N 20-275 P TS QS SURGE PROTECTIVE DEVICE, PACKING UNIT: 1

SURGE PROTECTIVE DEVICES SPD TYPE 2 PROTECT LOW-VOLTAGE CONSUMER SYSTEMS AGAINST SURGE VOLTAGES AS THEY ARE TESTED AS SPD TYPE 2 ACCORDING TO IEC 61643-11. THE DEVICES ARE COMPATIBLE WITH THE SYSTEM PRO M COMPACT SERIES. THE SPD WITH "TS" ARE OPTIONALLY EQUIPPED WITH A AUXILIARY CONTACT. PACKING UNIT: 1

OVR T2 3N 40-275 P QS SURGE PROTECTIVE DEVICE, PACKING UNIT: 1

OVR ZP+ 3N 12.5-255 MCB6 FOR METER BOARD BUSBAR,12.5KA IMP, TT & TNS, PACKING UNIT: 1

THE CT-MFC.12 IS A MULTIFUNCTION ELECTRONIC TIME RELAY FROM THE CT-C TIMER RANGE. IT PROVIDES 7 TIMING FUNCTIONS WITH 7 TIME RANGES FROM 0.05 S TO 100 H. THIS TIME RELAY OPERATES WITH A RATED CONTROL SUPPLY VOLTAGE OF 24 - 48 V DC / 24 - 240 V AC AND HAS A 1 C/O (SPDT) OUTPUT RATED AT 250 V / 4 A. A CONTROL INPUT WORKS WITH VOLTAGE-RELATED (NON-FLOATING) TRIGGERING. PACKING UNIT: 1
